Juniper SRX5K-SCB3-BB

New & Used Juniper SRX5K-SCB3-BB

Juniper SRX5K-SCB3-BB from ICP Networks

ICP Networks buy and sell Juniper SRX5K-SCB3-BB, and the large inventory of stock which we hold at our state of the art headquarters often allows us to offer same day shipping throughout the UK, with next day service across Europe and around the world on the parts you require.

ICP Networks buy and sell Juniper SRX5K-SCB3-BB, and the large inventory of stock which we hold at our state of the art headquarters often allows us to offer same day shipping throughout the UK, with next day service across Europe and around the world on the parts you require.

Please request a quote - We're ready to help

New And Used Juniper SRX5K-SCB3-BB

SRX5K Series

If for any reason you are unable to locate the Juniper SRX5K-SCB3-BB, or anything else you are looking for, please CONTACT one of our team.

ICP Networks stocks a wide range of new / used Juniper SRX5K-SCB3-BB, as well as the other SRX5K-SCB3-BB Routers, Switches and IP Phones which will allow a business of any size to put together a state of the art communications network specifically tailored to meet its needs, both now and in the future.

We also buy back excess and unwanted IT and networking equipment which has a resale value, allowing our customers to realise the cash value of unwanted technology assets, or reduce the cost of an upgrade or installation. Call us on +44 1625 468 450 and our customer care team will take the time to set out all the options ICP Networks offers for building a system to exactly meet your needs.

More From Juniper SRX5K Series

50 SCB MX240 EX SRX3600 TX Matrix Plus EX2300-C SRX3400 M7i QFX



Juniper SRX5K-SCB3-BB Specifications

General Information

Manufacturer Juniper Networks, Inc
Manufacturer Part Number SRX5K-SCB3-BB
Manufacturer Website Address http://www.juniper.net
Brand Name Juniper
Product Model SRX5K-SCB3-BB
Product Name SRX5K-SCB3-BB Switch Control Module
Product Information

The SRX5K-SCB3 (SCB3) caters to high-end security markets requiring support for higher capacity traffic, greater interface density (slot and capacity scale), and improved services. The SCB3 is supported on SRX5400, SRX5600, and SRX5800 Services Gateways.

The SCB3 supports the standard midplane and the enhanced midplane.

Some key attributes of the SCB3 are:

  • With the existing midplane and fabric link speed of 8.36 Gbps, supports a bandwidth of 205 Gbps per slot with redundant fabric support and 308 Gbps per slot without redundancy.
  • With the enhanced midplane and fabric link speed of 10.2 Gbps, supports a bandwidth of 249 Gbps per slot with redundant fabric support and 374 Gbps per slot without redundancy with the enhanced midplane
  • Improved fabric performance with the next-generation fabric (XF2) chip.
  • Full performance with fabric redundancy for higher-capacity line cards.
  • Support for MPC line cards such as SRX5K-MPC (IOC2) and IOC3 (SRX5K-MPC3-40G10G or SRX5K-MPC3-100G10G) only.
  • Two 10-Gigabit Ethernet SFP+ ports (These ports are disabled and reserved for future use).
Packaged Quantity 1
Product Type Switch Control Module

Technical Information

Application/Usage Optical Network
Data Networking

Media & Performance

Media Type Supported Optical Fiber
Ethernet Technology 10 Gigabit Ethernet
Network Technology 10GBase-X

I/O Expansions

Number of Total Expansion Slots 2
Expansion Slot Type SFP+

Miscellaneous

Compatibility Juniper Networks Services Gateway:
  • SRX5400
  • SRX5600
  • SRX5800



Why Choose Juniper SRX5K-SCB3-BB?

SRX5K Series - SRX5K-SCB3-BB

The SRX5K-SCB3 (SCB3) caters to high-end security markets requiring support for higher capacity traffic, greater interface density (slot and capacity scale), and improved services. The SCB3 is supported on SRX5400, SRX5600, and SRX5800 Services Gateways.

The SCB3 supports the standard midplane and the enhanced midplane.

Some key attributes of the SCB3 are:

  • With the existing midplane and fabric link speed of 8.36 Gbps, supports a bandwidth of 205 Gbps per slot with redundant fabric support and 308 Gbps per slot without redundancy.
  • With the enhanced midplane and fabric link speed of 10.2 Gbps, supports a bandwidth of 249 Gbps per slot with redundant fabric support and 374 Gbps per slot without redundancy with the enhanced midplane
  • Improved fabric performance with the next-generation fabric (XF2) chip.
  • Full performance with fabric redundancy for higher-capacity line cards.
  • Support for MPC line cards such as SRX5K-MPC (IOC2) and IOC3 (SRX5K-MPC3-40G10G or SRX5K-MPC3-100G10G) only.
  • Two 10-Gigabit Ethernet SFP+ ports (These ports are disabled and reserved for future use).

If for any reason you are unable to locate the Juniper SRX5K-SCB3-BB, or anything else you are looking for, please CONTACT one of our team.
