Cisco PA-A6-OC3SML

New & Used Cisco PA-A6-OC3SML

Cisco PA-A6-OC3SML from ICP Networks

ICP Networks buy and sell Cisco PA-A6-OC3SML, and the large inventory of stock which we hold at our state of the art headquarters often allows us to offer same day shipping throughout the UK, with next day service across Europe and around the world on the parts you require.

ICP Networks buy and sell Cisco PA-A6-OC3SML, and the large inventory of stock which we hold at our state of the art headquarters often allows us to offer same day shipping throughout the UK, with next day service across Europe and around the world on the parts you require.

Please request a quote - We're ready to help

New And Used Cisco PA-A6-OC3SML

Cisco 7600 FlexWAN Module*

If for any reason you are unable to locate the Cisco PA-A6-OC3SML, or anything else you are looking for, please CONTACT one of our team.

ICP Networks stocks a wide range of new / used Cisco PA-A6-OC3SML, as well as the other PA-A6-OC3SML Routers, Switches and IP Phones which will allow a business of any size to put together a state of the art communications network specifically tailored to meet its needs, both now and in the future.

We also buy back excess and unwanted IT and networking equipment which has a resale value, allowing our customers to realise the cash value of unwanted technology assets, or reduce the cost of an upgrade or installation. Call us on +44 1625 468 450 and our customer care team will take the time to set out all the options ICP Networks offers for building a system to exactly meet your needs.



Cisco PA-A6-OC3SML Specifications

General Information

Manufacturer Cisco Systems, Inc
Manufacturer Part Number PA-A6-OC3SML
Manufacturer Website Address http://www.cisco.com
Brand Name Cisco
Product Model PA-A6-OC3SML
Product Name One-port ATM OC-3c/STM-1 Single-mode (LR) Port Adapter
Product Type Port Adapter

Technical Information

Application/Usage Data Networking

Interfaces/Ports

Total Number of Ports 1
Connector Type SC
Interfaces/Ports Details 1 x SC Duplex OC-3c/STM-1

Media & Performance

Media Type Supported Optical Fiber
Fiber Optic Cable Standard 9 µm
Fiber Mode Supported Single-mode
Maximum Distance Supported 40 km
Maximum Data Transfer Rate 155.52 Mbit/s

Miscellaneous

Additional Information
  • Wavelength: 1310 nm
  • Up to 8191 simultaneously available virtual circuits (VCs)
  • Up to 2000 simultaneous segmentations and reassemblies (SARs)
  • ATM adaptation layer 5 (AAL5) for data traffic
  • Full available bit rate (ABR) support (Traffic Management 4.0), all modes
  • Traffic shaping per VC rates from 2.3 kbps to 155 Mbps, in 2.3-kbps increments
Compatibility
  • Cisco 7200 series router
  • Cisco 7200VXR series router
  • Cisco 7301 router
  • Cisco 7401ASR routers
  • Cisco 7500 series routers using VIP4-50 and VIP4-80
  • Cisco 7600 series routers using FlexWAN modules



Why Choose Cisco PA-A6-OC3SML?

Cisco 7600 FlexWAN Module* - PA-A6-OC3SML

The PA-A6-OC3SML is a single-width, single-port, ATM port adapter for the Cisco 7200 series router, Cisco 7200VXR series router, Cisco 7301 router, Cisco 7401ASR routers, Cisco 7500 series routers, and Cisco 7600 series routers with FlexWAN. With advanced ATM features, the PA-A6-OC3SML supports broadband aggregation, WAN aggregation, and campus/MAN aggregation.
