| Manufacturer | Dell Technologies |
|---|---|
| Manufacturer Part Number | 210-APHK |
| Manufacturer Website Address | http://www.dell.co.uk |
| Brand Name | Dell EMC |
| Product Line | PowerSwitch |
| Product Series | S5200-ON |
| Product Model | S5232F-ON |
| Product Name | PowerSwitch S5232F-ON Ethernet Switch |
| Product Type | Ethernet Switch |
| Uplink Port | Yes |
|---|---|
| Modular | Yes |
| Port/Expansion Slot Details | 32 x 100 Gigabit Ethernet Expansion Slot |
| 2 x 10 Gigabit Ethernet Expansion Slot |
| Media Type Supported | Optical Fiber |
|---|---|
| Ethernet Technology | 10 Gigabit Ethernet |
| 100 Gigabit Ethernet | |
| Network Technology | 10GBase-X |
| 100GBase-X |
| Number of Total Expansion Slots | 34 |
|---|---|
| Expansion Slot Type | SFP+ |
| QSFP28 | |
| Number of SFP+ Slots | 2 |
| Layer Supported | 3 |
|---|---|
| Networking Standards | IEEE 802.1ab |
| IEEE 802.3ad | |
| IEEE 802.1D | |
| IEEE 802.1p | |
| IEEE 802.1Q | |
| IEEE 802.1Qbb | |
| IEEE 802.1Qaz | |
| IEEE 802.1x | |
| IEEE 802.3ac | |
| IEEE 802.3x | |
| IEEE 802.1s | |
| IEEE 802.1w | |
| IEEE 802.1t |
| Manageable | Yes |
|---|
| Input Voltage | 120 V AC |
|---|---|
| 230 V AC | |
| Frequency | 50 Hz |
| 60 Hz | |
| Power Source | Power Supply |
| Redundant Power Supply Supported | Yes |
| Number of Power Supplies Supported | 2 |
| Power Consumption | 635 W |
| Compatible Rack Unit | 1U |
|---|---|
| Form Factor | Rack-mountable |
| Height | 43.2 mm |
| Width | 434.3 mm |
| Depth | 459.7 mm |
| Weight (Approximate) | 9.80 kg |
| Environmentally Friendly | Yes |
|---|---|
| Country of Origin | Poland |
High-performance, open networking 25GbE top-of-rack and 100GbE spine/leaf switches
The PowerSwitch S5200-ON 25/100GbE fixed switches comprise Dell Technologies’ latest disaggregated hardware and software data center networking solutions, providing state-of-the-art, highdensity 25/100GbE ports and a broad range of functionality to meet the growing demands of today’s data center environment. These innovative, next-generation open networking switches offer optimum flexibility and cost-effectiveness for web 2.0, enterprise, mid-market and cloud service provider with demanding compute and storage traffic environments.
The S5200-ON is a complete family of switches:12-port, 24-port, and 48-port 25GbE/100GbE ToR switches, 96-port 25GbE/100GbE Middle of Row (MoR)/End of Row (EoR) switch, and a 32-port 100GbE Multi-Rate Spine/Leaf switch. From the compact half-rack width S5212F-ON providing an ideal form factor for hyper-converged deployments, to the high density S5296FON for Middle of Row deployments, the S5200-ON series offers performance and flexibility for a variety of network designs.
In addition to 100GbE Spine/Leaf deployments, the S5232F-ON can also be used in high density deployments using breakout cables to achieve up to 128 10GbE or 128 25GbE ports.
Using industry-leading hardware and a choice of Dell EMC SmartFabric OS10 or select 3rd party network operating systems and tools, the S5200-ON switches incorporate multiple architectural features that optimize data center network flexibility, efficiency and availability, including IO panel to PSU or PSU to IO panel airflow for hot/cold aisle environments, redundant, hot-swappable power supplies and fans and deliver non-blocking performance for workloads sensitive to packet loss.
Priority-based flow control (PFC), data center bridge exchange (DCBX) and enhanced transmission selection (ETS) make the S5200-ON family ideally suited for DCB environments.
Dell EMC PowerSwitch S5200-ON switches support the open source Open Network Install Environment (ONIE) for zero touch installation of Dell EMC SmartFabric OS10 networking operating system, as well as alternative network operating systems.
